UHMWPE
2023/5/24
Ultra high molecular weight polyethylene fiber is currently a fiber with high specific strength and modulus in the world, spun from polyethylene with a molecular weight of 1-5 million. It has super tensile force, ultra-low elongation, acid and alkali resistance, high modulus and light specific gravity, UV resistance, anti-aging and other characteristics, and is widely used in civil, military, aviation, aerospace and other fields.
Product Name: UHMWPE Line High horsepower Stranded Wire
Product material: Ultra high molecular weight polyethylene fiber
Product structure: 2 shares, 3 shares, 4 shares (supporting specification customization)
Product specifications: 200D/3, 400D/3, 800D/3, 1000D/3, 1500D/3 (supports specification customization)
Product colors: white, black, blue, gray (supports color customization)
Product characteristics: high strength, high tensile strength, wear resistance, UV resistance, corrosion resistance, etc
Product applications: industrial ropes, marine fisheries, aerospace, military equipment, outdoor off-road, rescue traction and other fields.
Specification parameter table for ultra-high molecular weight polyethylene wire (100g/roll)
Model(D)
Tex
Diameter(mm)
Strength(cN)
Length/meter
200D/2
40
0.20
11195
2095
200D/3
60
0.25
16795
1380
400D/2
80
0.30
22390
1035
400D/3
120
0.35
33580
690
1000D/2
200
0.40
52770
416
1000D/3
300
0.52
79168
280
1500D/3
450
0.60
118750
180
Customizable specification packaging
Product Name:
Ultra high molecular weight polyethylene sewing thread
Main raw materials:
UHMWPE
Article number:
SL-03
Brand:
Shuang Li
Processing customization:
Support
Applicable scope:
Bulletproof materials, cutting and stab prevention equipment, sports equipment, ropes, rescue ropes, fishing trawls and cages, special umbrella ropes for aerospace and aviation purposes
物理性能 Physical Properties
序号NO
物理性能Physical Properties
指标Index
1
回潮Moisture regain
无NO
2
沸水收缩率Hot water shrinkage
<1%
3
亲水性Hydrophilicity
无NO
4
耐酸性Acid resistance
优Fine
5
耐多数化学试剂性Resistance to manychemical reagents
优Fine
6
耐紫外光Anti UV
持久Durable
7
熔点Melting Point
135~145℃
8
导热率(沿纤维轴向)Thermal conductivity(Along fibre Axis)
20w/m k
9
热膨胀系数Conefficient of thermal expansion
-12x10^6/K
10
电阻Resistance
<10A14Ω
11
介电常数Dielectric constant(22℃,10GHhz)
2.25
12
介电强度Dielectric strength
900kV/cm
13
损耗因数Dissipation factor
2x10-4
14
蠕变Creep deformation(22℃,20%负荷Load)
每天1x10-2%
15
耐碱性Alkali resistance
优Fine
